Details
| Model | ATQ8000 |
| Rated Line Pull | 8000 lb(3629 kg) single line |
| Motor | 4.13kw/3.0hp 12V Permanent Magnet |
| Control | Remote Switch,12ft(3.7m)lead |
| Gear Reduction ratio | 195.8:1 |
| Clutch | Sliding Ring Gear |
| Break Action | Automatic In-The-Drum |
| Drum Size | Φ2.6"x8.8"(Φ64mm x 224mm) |
| Rope Size | Φ5/16"x94'(Φ8.1mm x 28m ) |
| Mounting Bolt | 254mm x 114.3mm |
| Overall Dimension | 21.1"x6.3"x8.6"(537mm x 160mm x 218mm) |
| Packing size | 57X19x34.5cm 1PC/CTN |
| Weight | 33 kg/35 kg |
Line Pull and Cable Capacity
| Line Pull | lb | 0 | 2000 | 4000 | 6000 | 8000 | |
| kg | 0 | 907 | 1814 | 2721 | 3629 | ||
| Line Speed | ft/min | 22.5 | 11.48 | 8.53 | 8.53 | 5 | |
| m/min | 6.85 | 3.5 | 2.6 | 2.0 | 1.4 | ||
| Motor | Amps | 65 | 90 | 120 | 180 | 210 | |
Line Pull and Cable Capacity
| Layers of cable | 1 | 2 | 3 | 4 | |
| Rated Line | lb | 8000 | 6500 | 5500 | 4800 |
| Pull per layer | kg | 3629 | 2948 | 2495 | 2173 |
| Cumulative | ft | 19.6 | 42.6 | 68.9 | 92 |
| Cable Capacity | m | 6.0 | 13 | 21 | 28 |
